tennant t1 parts manual
This manual provides comprehensive information on the parts for the Tennant T1 floor scrubber. It includes parts listings, diagrams, and ordering instructions. It also mentions that only Tennant Company supplied or equivalent parts should be used. The manual covers models 9004191 and 9006285.
The Tennant T1 is a compact, walk-behind micro scrubber designed for efficient cleaning in tight spaces. Its small size allows it to easily navigate through entryways, aisles, and other narrow areas, making it ideal for various commercial and industrial environments. The T1 minimizes the risk of slip-and-fall accidents by effectively recovering water, leaving floors clean and dry.
This parts manual provides detailed information for models 9004191 (120V) and 9006285 (North America/Japan), covering machines with serial numbers ranging from 10000000 to 20000000. The Tennant T1 features a 3-gallon (11L) solution tank, providing up to 30 minutes of uninterrupted cleaning. It is available in corded and battery-powered versions, including AGM and Lithium-ion battery options.
The manual includes sections on how to order parts, electrical diagrams (120V/230V), and detailed breakdowns of various components such as the handle group, frame group, tanks and shroud group, scrub head group, and squeegee group. The Tennant T1 is suitable for use in various locations, including retail stores, schools, and healthcare facilities.
Availability of Tennant T1 Parts
Finding the right parts for your Tennant T1 floor scrubber is essential for maintaining its optimal performance. Whether you need aftermarket parts or spare components for a new or used machine, a wide range of options is available. You can source brushes, squeegees, motors, and other vital components from various suppliers;
OEM (Original Equipment Manufacturer) Tennant parts are readily accessible through authorized dealers, ensuring you receive high-quality, genuine components designed specifically for your T1 scrubber. These parts guarantee a perfect fit and reliable operation.
Many suppliers offer worldwide shipping, making it convenient to obtain the necessary parts regardless of your location. Online platforms, phone orders, fax orders, and mail orders are common methods for purchasing Tennant T1 parts. When ordering, it is crucial to identify the machine model and serial number to ensure you receive the correct components. This information can typically be found on the machine’s data label. Using the correct parts ensures that your Tennant T1 operates efficiently and effectively, prolonging its lifespan and maintaining its cleaning performance.
OEM Tennant Parts
When maintaining your Tennant T1 floor scrubber, opting for OEM (Original Equipment Manufacturer) parts is a crucial decision that significantly impacts the machine’s performance, longevity, and overall reliability. OEM parts are specifically designed and manufactured by Tennant, ensuring a precise fit and seamless integration with your T1 scrubber. This guarantees that each component functions optimally within the machine’s system.
Using OEM parts offers several advantages over aftermarket alternatives. First and foremost, OEM parts are made to the highest quality standards, rigorously tested to meet Tennant’s specifications. This results in superior durability and extended lifespan, reducing the frequency of replacements and minimizing downtime.
Additionally, OEM parts ensure compatibility with your T1 scrubber, preventing potential damage or malfunction that can arise from using ill-fitting or substandard aftermarket parts. By choosing OEM parts, you maintain the integrity of your machine and uphold its original performance capabilities. While OEM parts may have a higher initial cost, their long-term benefits, including enhanced reliability and reduced maintenance, make them a cost-effective investment for your Tennant T1 floor scrubber.
Standard Parts: Handle Group (120V)
The handle group of the Tennant T1 (120V) is a critical assembly for operating the scrubber. This section details the standard parts included in the handle group, ensuring proper control and functionality. Key components include the handle itself (part number 9005505), designed for the T1 120V model, providing the operator with a comfortable and ergonomic grip for maneuvering the machine.
The handle group also features a front/rear cover (part number 9004320), which is essential for protecting internal components and providing a finished look. A logo label (part number 1042589) and an operational instrument panel label (part number 1037324) are also included, ensuring clear identification and user guidance.
A rocker switch (part number 602919) is a vital part of the handle group, offering an on/off control mechanism for the scrubber. These parts are specifically designed for models with serial numbers ranging from 10000000 to 20000000, ensuring compatibility and optimal performance. Using the correct standard parts guarantees the handle group’s reliability and longevity, providing smooth and efficient operation of the Tennant T1 scrubber.
Standard Parts: Frame Group
The frame group of the Tennant T1 is the foundational structure supporting the scrubber’s components. This section outlines the standard parts essential for maintaining the frame’s integrity and functionality. Key components include various screws, such as the hex screw M8 X 1.25 X 16 (part number unspecified), which securely fastens different parts of the frame together, ensuring stability during operation.
Also included are brackets for the bumper wheel (part number 1034805), providing crucial protection against impacts and preventing damage to the scrubber. The chassis harness (part number 1033825) is a vital electrical component, facilitating the connection and distribution of power throughout the machine. This harness is essential for the proper functioning of all electrical systems within the T1 scrubber.
These standard parts are designed for Tennant T1 models with serial numbers ranging from 10000000 to 20000000, ensuring compatibility and optimal performance. Regular maintenance and replacement of these parts, when necessary, will help preserve the structural integrity and operational efficiency of the Tennant T1 frame group. Using only genuine or equivalent parts is crucial for maintaining the scrubber’s reliability.
Tanks and Shroud Group Parts
The tanks and shroud group of the Tennant T1 includes essential components for liquid storage and containment. This section details the standard parts necessary for maintaining this group’s performance. Key parts include the recovery tank with labels (part number 9004312), which stores the dirty water collected during scrubbing. A label (part number 1039085) is affixed to the side of the T1 scrubber, providing important information.
The tank handle kit (part number 9004285) facilitates easy handling and removal of the tank for emptying and cleaning. Various screws, such as the pan head screw M4 X 0.70 X 16 (part number 24265), are used to secure the tank and its components. These screws ensure a tight and leak-proof assembly.
These standard parts are designed for Tennant T1 models with serial numbers ranging from 10000000 to 20000000, ensuring compatibility and optimal performance. Regular maintenance and replacement of these parts, when necessary, will help preserve the functionality and hygiene of the Tennant T1 tanks and shroud group. Using only genuine or equivalent parts is crucial for maintaining the scrubber’s reliability. The tank cover group, although related, is a separate assembly.
Scrub Head Group Parts
The scrub head group is a critical assembly in the Tennant T1 floor scrubber, responsible for the actual cleaning of the floor. This section covers the standard parts required for the scrub head group, varying based on voltage (120V or 230V) and serial number ranges. For 120V models with serial numbers 10507590 and above, components include idler hubs, retaining rings, and idler plug shafts. Screws, such as the M6 X 1.00 X 16, ensure secure assembly.
For models with serial numbers between 10000000 and 10507589, the parts include flat washers, brush housings, and motor kits. The motor kit comes with sheaves and carbon brushes, essential for the motor’s operation. For 230V models, similar components are used, with variations to accommodate the higher voltage requirements;
Specific parts for the 230V scrub head group include brush filters rated at 270 Vdc and 3A. The scrub head lift group is a separate assembly that facilitates raising and lowering the scrub head. Regular maintenance and timely replacement of worn parts are essential to maintain the cleaning performance of the Tennant T1 scrubber. Always use Tennant Company supplied or equivalent parts for optimal performance and reliability.
Squeegee Group Components
The squeegee group is a vital part of the Tennant T1 floor scrubber, responsible for effectively removing water and cleaning solution from the floor after scrubbing. This section details the components for both the front and rear squeegee assemblies. Standard parts for the squeegee group include squeegee frames, inner squeegee blades made of urethane, and retainers to hold the blades in place.
The squeegee frame provides the structure and support for the squeegee assembly. The inner squeegee blade is critical for direct contact with the floor, ensuring efficient water pickup. Retainers, often made of acetal, secure the blades and maintain proper alignment for optimal performance.
Fasteners such as lock nuts (M4 X 0.70) are used to assemble the squeegee components securely. The parts manual also includes a wheel kit for the squeegee, enhancing its maneuverability and floor contact. Regular inspection and replacement of worn squeegee blades are essential for maintaining streak-free cleaning. Proper assembly and maintenance of the squeegee group ensure the Tennant T1 efficiently removes water, leaving floors dry and safe.
Electrical Diagrams (120V/230V)
This section provides detailed electrical diagrams for both the 120V and 230V versions of the Tennant T1 floor scrubber. These diagrams are essential for troubleshooting electrical issues, understanding the wiring configuration, and ensuring safe and proper repairs. The electrical system includes various components such as switches, motors, wiring harnesses, and control panels.
The 120V diagram (part number 1046178) illustrates the electrical layout for models operating on a 120V power supply, commonly used in North America and Japan. The 230V diagram (part number 1046179) depicts the electrical configuration for models designed for a 230V power supply, typically used in Europe and other regions.
These diagrams show the connections between different electrical components, including the power source, switches, motor, and other control elements. Understanding these diagrams is crucial for identifying faulty components, tracing circuits, and performing electrical repairs. Always disconnect the power supply before working on any electrical components to prevent injury or damage.
How to Order Parts
Ordering parts for your Tennant T1 floor scrubber is a straightforward process designed to get you the components you need quickly and efficiently. To ensure prompt delivery and avoid any confusion, follow these steps when placing your order. First, identify the machine model. This information can be found on the data label affixed to the scrubber.
Next, locate the machine’s serial number, which is also displayed on the data label. The serial number is crucial for identifying the specific configuration of your T1 model, ensuring that you receive the correct parts. With the model and serial number in hand, you can proceed to order parts.
Tennant Company offers several convenient ways to place your order. You can order parts online through the official Tennant website or authorized online retailers. Alternatively, you can place your order by phone, fax, or mail. Regardless of the method you choose, be sure to provide the machine model, serial number, and the part numbers of the items you wish to order. Using only Tennant Company supplied or equivalent parts is recommended.
